Description
Features: 1 1x2 HDMI splitter, supports deep 30bit, 36bit video color format, supports 24/50/60fs/HD?DVD/xvycc. 2 Digital audio format, DTS?HD / Dolby?TrueHD / DTS / Dolby?AC3 / DSD / HD (HBR). 3 HDMI resolution is up to 1920x1080/60Hz, the maximum bandwidth is 225MHz, and the maximum transmission rate is 2.25gbps. 4 The input supports AWG26 HDMI standard cable lengths up to 15m, and the output supports AWG26 cable lengths up to 20m. 5 Suitable for supermarkets, shopping malls, HDTVS, STB, DVD, data control centers, conference room presentations, education, training, theaters.
Specification:Item Type: HDMI Splitter
Material: ABS
HDMI Version: HDMI 1.4a
HDMI Resolution: Up to 1920x1080 / 60Hz
Support Video Color Format: 24bit/Dark 30bit, 36bit
Support Audio Format: DTS-HD / Dolby-TrueHD / DTS / Dolby-AC3 / DSD HD (HBR)
Maximum Bandwidth: 225MHz
Maximum Transmission Rate: 2.25gbps
TMDS Signal Input/Output: 0.5 to 1.5V pp (TTL)
DC Input/Output Signal: 5volts pp (TTL)
Input Cable Distance: Standard 15m AWG26 HDMI Cable
Output Cable Distance: Standard 20m AWG26 HDMI Cable
Maximum Working Current: 350mA
Operating Temperature Range: -15 - +55
Operating Humidity Range: 5 - 90% Rh (Non-Condensing)
Size: Approx. 62x51x11mm / 2.4x2.0x0.4in (L x W x H)
Data Line Length: Approx. 80cm / 31.5in
Package List:
1 x HDMI Splitter
1 x Data Line
What's in the box
1 x Adaptor
