Description
Changeover Switch DIN Mount, 230 Volt, 63 Amp AC21 at 240 Volt AC21, 3.6 Watt, 50/60 Hz, 2 Pole, Manual Actuator, 16 sq-mm Flexible/25 sq-mm Rigid, DIN Rail Mounting, Screw Connection, IP20, -25 to 50 deg C, 90 mm Height, 71.5 mm Width, 72 mm Depth
| Number of poles |
2 |
| Min. rated voltage |
230 V |
| Rated voltage |
230 V |
| Number of contacts as change-over contact |
2 |
| Width in number of modular spacings |
4 |
| Short-circuit breaking capacity (Icw) |
6 kA |
| Number of contacts as normally open contact |
0 |
| |
| Voltage type AC-DC |
AC |
| With signal lamp |
No |
| Degree of protection (IP) |
IP20 |
| Rated current |
63 A |
| Number of contacts as normally closed contact |
0 |
| Built-in depth |
72 mm |
| Switching function |
Control switch |
Brand: Hager
Manufacturer Part Number: SF263


Barcode: 3250615561008
